      管式捻股机、合绳机
      产品参数

      大轴承管式捻股合绳机主要技术参数


      型号捻制钢丝(股)径筒体最高转速捻距范围捻距方式牵引轮直径线架工字轮尺寸收线工字轮尺寸外形尺寸
      ModelInlet wire/strand diameterRotating speedLay length rangeLay length control Capstan diameter Tube bobbimTake-up bobbinOverrall size

      		mm国产轴承rpmmm
      		mm外径D*内芯d*内宽w(mm)外径D*内芯d*内宽w(mm)长L*宽W*高H(mm)
      GGZ6/2000.3-0.916007.99-32.87机械有级捻或变频无级捻
      Mechanical-control or Electrical-control
      		2*φ400200*75*130630*250*40010500*1600*1000
      GGZ12/2000.3-0.9150012.46-51.242*φ400200*75*130630*250*40018000*1600*1000
      GGZ18/2000.3-0.9140016.55-68.072*φ400200*75*130630*250*40022000*1600*1000
      GGZ24/2000.3-0.9130016.44-67.932*φ600200*75*1301000*400*60025500*2300*1400
      GGZ30/2000.3-0.9120016.44-67.932*φ600200*75*1301000*400*60031000*2300*1400
      GGZ36/2000.3-0.9110017.56-72.252*φ800200*75*1301000*400*60036000*2300*1400
      GGZ6/2500.4-1.014009.07-37.332*φ400250*90*140630*250*40013000*1600*1000
      GGZ12/2500.4-1.0130012.74-52.402*φ400250*90*140630*250*40018000*1600*1000
      GGZ18/2500.4-1.0120017.22-70.852*φ400250*90*140630*250*40023000*1600*1000
      GGZ24/2500.4-1.0110017.30-71.142*φ600250*90*1401000*400*60029000*2300*1400
      GGZ30/2500.4-1.0100017.30-71.142*φ600250*90*1401000*400*60034000*2300*1400
      GGZ36/2500.4-1.090017.77-73.092*φ800250*90*1401000*400*60039000*2300*1400
      GGZ6/3000.6-1.3130012.64-51.982*φ600300*120*174800*400*47015000*1800*1400
      GGZ9/3000.6-1.3120012.64-51.982*φ600300*120*174800*400*47018000*1800*1400
      GGZ12/3000.6-1.3120017.30-71.142*φ600300*120*1741000*400*60021000*2300*1400
      GGZ18/3000.6-1.3110025.06-103.082*φ600300*120*1741000*400*60026000*2300*1400
      GGZ24/3000.6-1.390029.48-121.272*φ800300*120*1741000*400*60031000*2300*1400
      GGZ25/3000.6-1.390029.48-121.272*φ800300*120*1741000*400*60033500*2300*1400
      ZZG30/3000.6-1.380029.48-121.272*φ800300*120*1741000*400*60037000*2300*1400
      GGZ36/3000.6-1.380029.48-121.272*φ800300*120*1741000*400*60042000*2300*1400
      GGZ6/4001.2-2.590020.30-83.492*φ800400*160*2221000*400*60018000*2300*1400
      GGZ9/4001.2-2.580020.30-83.492*φ800400*160*2221000*400*60023000*2300*1400
      GGZ12/4001.2-2.580029.22-120.202*φ1000400*160*2221300*630*76027000*2500*1600
      GGZ18/4001.2-2.570043.70-179.742*φ1000400*160*2221300*630*76035000*2500*1600
      GGZ24/4001.2-2.565048.06-201.812*φ1200400*160*2221600*800*80042000*2800*1900
      GGZ25/4001.2-2.565048.06-201.812*φ1200400*160*2221600*800*80044000*2800*1900
      GGZ30/4001.2-2.560048.06-201.812*φ1200400*160*2221600*800*80049000*2800*1900
      GGZ36/4001.2-2.560048.06-201.812*φ1200400*160*2221600*800*80056000*2800*1900
      GGZ40/4001.2-2.560048.06-201.812*φ1200400*160*2221600*800*80062000*2800*1900
      GGZ48/4001.2-2.550048.06-201.812*φ1200400*160*2221600*800*80068000*2800*1900
      GGZ6/5001.5-3.580039.94-164.282*φ1000500*200*3001300*630*76022000*2500*1600
      GGZ9/5001.5-3.570039.94-164.282*φ1000500*200*3001300*630*76027000*2500*1600
      GGZ12/5001.5-3.570049.51-203.642*φ1200500*200*3001600*800*80032000*2800*1900
      GGZ18/5001.5-3.560073.95-304.212*φ1200500*200*3001600*800*80041000*2800*1900
      GGZ24/5001.5-3.560074.63-307.012*φ1250500*200*3001600*800*80051000*2800*1900
      GGZ25/5001.5-3.560074.63-307.012*φ1250500*200*3001600*800*80053000*2800*1900
      GGZ30/5001.5-3.550074.63-307.012*φ1250500*200*3001600*800*80061000*2800*1900
      GGZ36/5001.5-3.550074.63-307.012*φ1250500*200*3001600*800*80069000*2800*1900
      GGZ40/5001.5-3.550074.63-307.012*φ1250500*200*3001600*800*80076000*2800*1900
      GGZ48/5001.5-3.540074.63-307.012*φ1250500*200*3001600*800*80090000*2800*1900
      GGZ6/6302.0-5.060048.52-199.582*φ1200500*200*3001300*630*76029000*2500*1600
      GGZ9/6302.0-5.050048.52-199.582*φ1200630*240*4001300*630*76037000*2500*1600
      GGZ12/6302.0-5.050060.51-248.902*φ1200630*240*4001600*800*80041000*2800*1900
      GGZ18/6302.0-5.040090.76-373.342*φ1200630*240*4001800*850*110053000*2800*1900
      GGZ24/6302.0-5.0350110-5502*φ1400630*240*4002000*900*122065000*2800*2600
      GGZ25/6302.0-5.0350110-5502*φ1400630*240*4002000*900*122067000*2800*2600
      GGZ30/6302.0-5.0300110-5502*φ1600630*240*4002000*900*122077000*2800*2600
      GGZ36/6302.0-5.0300110-5502*φ1600630*240*4002000*900*122089000*2800*2600
      GGZ40/6302.0-5.0250110-5502*φ1800630*240*4002000*900*1220102000*2800*2600
      GGZ48/6302.0-5.0250110-5502*φ1800630*240*4002000*900*1220122000*3500*3200


      电梯绳在线预张拉机组


      型号捻制股绳径筒体最高转速捻距范围捻距方式牵引轮直径在线张力线架工字轮尺寸收线工字轮尺寸外形尺寸
      ModelInlet strand//wire diameterRotating speedLay length rangeLay length control Capstan diameter Stretching forceTube bobbimTake-up bobbinOverrall size

      		mm国产轴承rpmmm
      		mmKN外径D*内芯d*内宽w(mm)外径D*内芯d*内宽w(mm)长L*宽W*高H(mm)
      GGZ9/400在线张拉1.5-4.0//5.0-12.080030-120机械有级捻或变频无级捻2*Φ1250（两组）R860400*160*2221000*400*60039000*1800*2000
      GGZ9/500在线张拉1.9-5.5//6.0-16.065030-130Mechanical-control 2*Φ1250（两组）R1080500*200*3001300*630*76045000*2000*2200
      GGZ9/630在线张拉3.0-7.0//10.0-22.050060-145or Electrical-control2*Φ1250（两组）R13120630*240*4001600*800*80054000*2200*2400
